Replacing a yacht generator is not a matter of finding a unit that fits the old footprint. The correct choice must support the yacht's real simultaneous electrical demand, including motor starting loads, without leaving the diesel chronically underloaded.
The installation review must then cover the mounting base, physical clearance, ventilation, raw-water cooling, wet exhaust, fuel connections, controls, output wiring and shore-power isolation. This guide explains what the captain and engineer should establish before removal and what must be checked before commissioning.
Size from the operating load, not the old casing
Start with a list of equipment that may operate at the same time. Use appliance nameplates wherever they are available. If a nameplate gives watts, record that figure; if it gives only amps, Northern Lights says to multiply amps by voltage to obtain wattage for the load estimate.
The list needs to reflect how the yacht is actually operated. Air conditioning and watermakers matter because their motors can impose a much higher demand while starting than while running. Northern Lights says motors and motor loads may require several times full-load current and illustrates starting demand of up to ten times running wattage.
A useful schedule should record:
- Normal simultaneous loads. List the equipment expected to run together, rather than adding every appliance aboard without regard to operating practice.
- Nameplate information. Capture watts or, where only current is shown, amps and voltage.
- Starting loads. Identify major motors and compressors separately so their starting demand is not hidden inside running totals.
- Electrical format. Record the vessel's voltage, phase and frequency requirements before selecting equipment.
- Three-phase distribution. Divide simultaneous loads equally across the output legs. An imbalance can lower voltage on the loaded leg and raise it on the unloaded leg.
The result is a load profile, not simply one total. It should show which equipment runs continuously, what starts while other loads are present and how demand changes with the yacht's operating mode. The replacement can then be assessed against realistic combinations.
Why bigger is not automatically better
A generator that is too small may struggle to start motors in air conditioners or watermakers. A set chosen only from running watts can therefore appear adequate on paper but fail when a compressor or pump starts.
Oversizing creates a different problem. Northern Lights warns that an oversized diesel can run overly cool, with carboning of injectors and valves and raw fuel entering the exhaust. Its installation manual uses a rule of thumb that continuous load should be at least 50% of generator capacity and notes that two smaller sets may be advantageous.
That percentage belongs to Northern Lights' guidance, so it should not be detached from the relevant manufacturer and model documentation. The selection decision must reconcile routine load, starting demand and the yacht's different operating states rather than targeting the largest theoretical number.
| Design issue | What can go wrong | Engineering response |
|---|---|---|
| Running load too high | Motors may be difficult to start | Recalculate simultaneous and starting loads |
| Generator oversized | Diesel may run overly cool | Compare capacity with the real load profile |
| Three-phase imbalance | Voltage falls or rises between legs | Divide loads equally across output legs |
| Poor physical clearance | Flexible-mounted unit cannot move freely | Check all-round clearance before selection |
| Wet-exhaust backflow | Engine damage and possible flooding | Review outlet, waterlift and exhaust route |
| No transfer isolation | Shore and generator power can interconnect | Fit an approved switching device |
If the load study suggests a change of output frequency, phase or wider integration with an inverter system, treat that as an electrical design project. It is not a like-for-like machinery swap, and it belongs with a qualified marine electrical and electronics review.
Check the footprint, mounts and maintenance envelope
Dimensions on a product sheet do not establish whether a generator will fit properly. The proposed location must provide structural support, ventilation, cooling and exhaust arrangements, as well as access for regular maintenance, fuel adjustment and eventual removal or overhaul.
The generator requires a rigid mounting base. It also needs adequate clearance on all sides for movement on flexible mounts, with flexible connections on all lines and connections. A casing that clears the compartment while stationary may still be unsuitable if movement, hose routing or service access is restricted.
Before the existing set is removed, document the installation thoroughly:
- Measure and photograph the footprint and mounting arrangement.
- Record clearance around the casing and the routes by which air enters and leaves the space.
- Photograph the raw-water seacock, inlet strainer, impeller access and heat-exchanger zinc access.
- Trace the wet-exhaust route and note the waterlift arrangement.
- Record the fuel supply and return connections.
- Identify control wiring, AC output connections and the shore-to-generator transfer arrangement.
- Consider how the replacement could later be removed for overhaul.
This survey determines whether the work remains within the existing machinery space or needs structural alteration and wider yacht refit management. Do not assume the old mounts, hoses or routes suit the new unit merely because its external dimensions are similar.
Review cooling, exhaust and fuel connections
The raw-water system must remain serviceable after installation. Northern Lights specifically calls for access to the seacock, inlet strainer, impeller and heat-exchanger zincs. Positioning a new casing or sound enclosure across these items turns routine service into dismantling work and may obstruct urgent access to the seacock.
Wet exhaust requires particular attention because water flowing back into the engine can damage it and possibly flood the boat. Northern Lights says the exhaust outlet must be above the load waterline. For its waterlift arrangement, it specifies that the muffler sits below the exhaust manifold and that the outlet loop is at least 12 inches (30 cm) above the waterline.
Those dimensions are Northern Lights installation requirements, not universal measurements for every generator. The engineer must check the selected manufacturer's documents and assess the yacht's actual waterline and exhaust geometry. Any proposal to retain or alter the exhaust waterlock, through-hull or raw-water system requires design review.
Fuel supply and return connections also form part of the installation survey. Record their routes and connection points before removal, then assess them with the replacement unit rather than assuming they can be reused unchanged. The same principle applies to ventilation and every flexible connection.
Controls, switching and the final installation scope
A replacement may require different controls and AC connections even where its nominal output suits the yacht. Document the existing interfaces before disconnection so the engineer can compare them with the proposed set and define the work accurately.
Generator power and shore power must be separated by an approved switching device. Kohler's operation guidance specifies a ship-to-shore transfer switch to prevent interconnection. This separation prevents electrical backfeed and dangerous interconnection, so transfer arrangements must not be improvised or altered without an approved design.
The installation scope should therefore cover:
- Output configuration. Confirm voltage, phase and frequency against the vessel's requirements.
- Load distribution. For three-phase work, plan equal division across the output legs.
- Control integration. Identify the existing control and monitoring connections before removal.
- Power transfer. Verify how shore and generator supplies remain separated.
- Mechanical interfaces. Review the base, flexible mounts and flexible connections.
- Service access. Preserve access to adjustment points, raw-water items and a future removal route.
Sound treatment cannot be considered separately from these requirements. Any enclosure or revised arrangement still has to preserve ventilation, all-round clearance, flexible-mounted movement and maintenance access. Generator installation is complex work requiring specialist knowledge and tools, and Northern Lights recommends qualified dealer or boatyard installation, with owner installations reviewed by a qualified inspector.
What crew can check safely
Crew can collect the information needed for selection without changing the installation. This reduces assumptions at survey stage and helps distinguish a straightforward replacement from a larger integration job.
- Prepare the load list. Include every AC and DC load that may operate simultaneously, with nameplate watts or amps and voltage. Mark major motor and compressor starting loads.
- Photograph before removal. Capture the footprint, service space, air paths, mounts, raw-water components, exhaust route, fuel supply and return, controls and AC connections.
- Record the vessel's supply requirements. Note voltage, phase and frequency, then identify the existing shore-to-generator transfer arrangement.
- Leave switching unchanged. Do not alter shore, generator or inverter interconnections without an approved design.
These are observation and documentation tasks. The technical survey should follow while the original arrangement is still visible, particularly where hoses, cables or exhaust sections disappear behind joinery or machinery.
When to call an engineer
Call an engineer for any generator replacement, not only when the proposed set differs from the old one. Output-frequency conversion, a phase change or integration with shore-power and inverter systems all widen the engineering scope.
Engineering input is also required when the replacement needs changes to:
- structural supports or the mounting base
- the exhaust waterlock or route
- the through-hull or raw-water system
- fuel supply or return lines
- machinery-space ventilation
- transfer switching
Stop the project for review if there is any risk of exhaust-water backflow, fuel leakage, electrical backfeed or inadequate service access. These are design and safety issues, not snags to resolve after the unit has been lowered into place.
Blueward Marine provides marine generator service in Mallorca, including replacement planning and related technical work. Submit the fault and photos through the online service booking, or call the 24/7 line on +34 971 251 374.
Frequently asked questions
How do I size a replacement yacht generator?
List all equipment likely to operate simultaneously using nameplate watts. Where only amps appear, Northern Lights says to multiply amps by voltage. Add separate consideration for motor and compressor starting demand, which can be several times full-load current. Then compare the resulting operating profiles with the proposed generator rather than selecting from footprint or running watts alone.
Why is a larger yacht generator not always better?
Northern Lights warns that an oversized diesel can operate overly cool, causing carboning of injectors and valves and pumping raw fuel into the exhaust. Its guidance uses a continuous-load rule of thumb of at least 50% of generator capacity. Selection should balance normal demand, motor starting loads and the yacht's actual operating modes.
What must be reviewed when replacing a marine generator?
Review the load profile, voltage, phase, frequency, structural base, flexible mounts, clearance, ventilation, fuel supply and return, raw-water cooling, wet exhaust, controls, AC output and shore-power transfer isolation. Keep the seacock, strainer, impeller and heat-exchanger zincs accessible, and retain a workable route for future removal or overhaul.
