Reverse-cycle yacht heating in cold seawater

Reverse-cycle air conditioning can heat a yacht effectively, but its output depends on the seawater supplying the system. As that water gets colder, some systems lose heating capacity before they reach their low-temperature limit.

This guide explains the heat-pump principle, the model-specific limits published by Webasto, Dometic and Frigomar, and the difference between reduced output and a fault. It also covers safe crew checks, winter lay-up routines and auxiliary heating options.

How reverse-cycle heating moves heat

A reverse-cycle marine air-conditioning unit heats by reversing its refrigerant flow. The reversing valve changes the refrigerant circuit so that the system takes heat from seawater and delivers it to the cabin air.

The seawater is therefore part of the heating process, not just a cooling medium for the machinery. When seawater temperature falls, the amount of heating available can fall as well. This means a unit can be running, with airflow and overboard discharge present, yet still take longer to satisfy the cabin set point.

That distinction matters during winter fault-finding. Weak cabin heat does not by itself prove that the reversing valve, refrigerant circuit or seawater side has failed. The engineer first needs the measured seawater temperature and the operating limits for the installed model.

Why the seawater limit depends on the equipment

There is no single seawater cut-off that applies to every yacht heat pump. Manuals from Dometic marine systems, Webasto and Frigomar equipment give different descriptions of capacity, operating limits and control behaviour.

Dometic's chilled-water manual makes a useful distinction between reduced capacity and the lowest temperature at which some heating remains available. It says capacity diminishes below 55°F (13°C), while some heat can still be provided down to 40°F (4°C). Crew may therefore notice declining cabin performance before the controller reaches a low-limit condition.

Dometic Elite controls have a default seawater low-limit of 40°F/4.4°C. Below that point, the control can switch to installed auxiliary electric heat after five minutes. If auxiliary heat is not fitted, the system can shut down instead.

Webasto's FCF manual rates effective heating down to 40°F, about 4.4°C, for that unit. Frigomar publishes heating seawater above 4°C for several 410-series chiller models. These figures should stay tied to those products, rather than being treated as universal settings.

Separating cold-water performance from a fault

Start with operating conditions before treating weak heat as a machinery failure. Open hatches or portholes increase cabin heat loss and are a documented reason for a reverse-cycle unit to run continuously. Close them during the test so that the result reflects the HVAC system rather than avoidable heat loss.

Return airflow also matters. Dometic identifies poor return airflow, blocked filters and restricted ducting as causes of a high-pressure condition in heating mode. A visible obstruction at the return grille or filter is therefore relevant when the controller reports a pressure fault.

The reversing valve is another possible fault point. Webasto identifies a stuck reversing valve as a cause of a no-heat symptom on its FCF equipment and directs the user to service if the manual's listed action does not resolve it. Electrical testing and refrigerant diagnosis should be left to an engineer.

A useful test record contains the actual seawater temperature, cabin set point, return-air condition, observed overboard flow and the exact controller alarm. Those details help distinguish three different situations: expected capacity loss in colder water, a control response at the low limit, or a fault that occurs within the manufacturer's operating range.

What crew can check safely

Keep the first inspection to operating observations and accessible airflow checks. Do not open the refrigerant circuit or move into electrical diagnosis when investigating a reversing-valve problem.

1. Measure the seawater temperature. Record the actual figure rather than assuming that water around a Mallorca berth is warm enough for the installed unit.
2. Record the demand. Note the cabin set point and the return-air condition while the system is calling for heat.
3. Observe the seawater discharge. Record whether overboard flow is visible during the test. Pass that observation to the engineer rather than using it alone to declare the seawater circuit serviceable.
4. Close the accommodation. Shut hatches and portholes so that avoidable heat loss does not distort the test.
5. Inspect accessible airflow points. Check the return grille, filter and visible duct openings for obstruction.
6. Copy the controller message. Record the complete pressure, freeze or low-seawater-limit alarm rather than clearing it without a note.
7. Check the system specification. Confirm whether auxiliary electric heat is installed before expecting an automatic changeover at low seawater temperature.

These checks produce a much clearer service brief than 'heating weak'. They also prevent two common diagnostic errors supported by the manuals: treating normal cold-water capacity loss as a failure, or assuming that every controller will change to backup heat.

Exercising the system during winter lay-up

A reverse-cycle system should not necessarily remain untouched throughout an inactive period. Webasto specifies two to three heat cycles per month for its FCF equipment to keep the reversing-valve internals moving.

Dometic gives a different routine for inactive chilled-water installations. Its manual recommends cycling chillers and airhandlers for 30-60 minutes once a month and cycling them into reverse mode as well.

Follow the interval for the installed equipment and the vessel's approved procedure. Do not combine the Webasto and Dometic instructions into a new generic schedule. The wider winter yacht lay-up checklist can be used to place the HVAC run into the vessel's planned care routine.

Record each exercise in the vessel log, including the mode selected and any alarm shown. If the vessel procedure permits operation in both modes, exercising reverse mode gives the reversing valve the movement specified by the manufacturer.

Auxiliary heat and when to call an engineer

Auxiliary heat needs to be identified as part of the installed design, not assumed from the controller menu. On a Dometic Elite control, the low-temperature logic can change to auxiliary electric heat only when that heat is fitted. Without it, the low-limit response can be a shutdown.

A diesel-based arrangement is another equipment-specific architecture. Webasto offers its BlueComfort Premium system combining marine air conditioning with a diesel water heater under central HVAC control. That product example does not mean every reverse-cycle plant can or should be converted in the same way.

Call an engineer when:

• Faults repeat after basic checks. Pressure, freeze or low-seawater-limit alarms continue after the accessible airflow and seawater-flow observations have been completed.
• The reversing valve is suspect. The system produces no heat and requires valve, electrical or refrigerant diagnosis.
• Output is poor within the operating range. Measured seawater temperature is within the installed model's published range, but heating remains inadequate.
• Backup heating is being considered. Auxiliary-electric or diesel-heater integration requires assessment against the existing plant and controls.

Give the engineer the model, seawater temperature, set point, return-air condition, overboard-flow observation and exact alarm. This allows the first assessment to use the correct manual limit rather than a generic cold-water figure.
